Bộ điều khiển Servo Mitsubishi MR-J4-10A 0.1kW 220V

Mã sản phẩm: 44451465

Liên hệ

SKU: MR-J4-10A
Thương hiệu: Mitsubishi
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT

Danh mục: Servo

Liên hệ báo giá

Mô tả sản phẩm

Primary brand	Mitsubishi Electric
Main function	AC servo drive
Product series / family name	MELSERVO J4 series
Sub-range name	MR-J4 series
Functions	AC motion servo drive / amplifiersine wave PWM control/current control method2-channel analog monitorSafe torque off (STO)fully closed loop controlload-side encoder interfacespeed control modetorque control modeadvanced vibration suppression control IIadaptive filter IIrobust filterauto tuningone-touch tuningtough drive functiondrive recorder functionmachine diagnosis functionpower monitoring Functionsuper trace controllost motion compensation
Design	built-in dynamic brake2-wire type communication methodnatural cooling
Supply voltage (AC)	200Vac-240Vac (200V class; 220Vac / 230Vac)
Type of network	Single-phase input (2P) or 3-phase input (3P)
Rated current	1.1A
Rated active power (kW)	100W / 0.1kW
Protection functions	overcurrent shut-offregenerative overvoltage shut-offoverload shut-off (electronic thermal)servo motor overheat protectionencoder fault protectionregenerative fault protectionundervoltage protectioninstantaneous power failure protectionoverspeed protectionexcessive error protectionmagnetic pole detection protectionlinear servo control fault protection
Communication protocol	RS-422RS-485
Net Height (mm)	156 mm
Net Width (mm)	40 mm
Net Depth (mm)	135 mm
Digital inputs	1 x digital input (24Vdc; sink/source) (EM2)1 x digital input (24Vdc; sink/source) (LSP)1 x digital input (24Vdc; sink/source) (LSN)1 x digital input (24Vdc; sink/source) (SON)1 x digital input (24Vdc; sink/source) (RES)1 x digital input (24Vdc; sink/source) (PC / ST1 / RS2)1 x digital input (24Vdc; sink/source) (TL / ST2 / RS1)1 x digital input (24Vdc; sink/source) (SP1)1 x digital input (24Vdc; sink/source) (SP2)
Digital outputs	1 x digital output (rly. contact type) (ALM)1 x digital output (rly. contact type) (ZSP)1 x digital output (rly. contact type) (TLC / VLC)1 x digital output (rly. contact type) (INP / SA)1 x digital output (rly. contact type) (RD)
Analog inputs	1 x analog input (0-10Vdc) (TLA / TC)1 x analog input (-10…+10Vdc) (VC / VLA)
Analog outputs	1 x analog output (-10…+10Vdc) (MO1)1 x analog output (-10…+10Vdc) (MO2)
Degree of protection	IP20
Dimensions	H156mm x W40mm x D135mm
Ambient air temperature for operation	0…+55 °C
Ambient air temperature for storage	-20°C…+65 °C
Current consumption	0.9A input
Power consumption(drive auxiliary power consumption)	30 W
Order code / Manufacturer SKU	MR-J4-10A
Manufacturer product status	Commercialized
Equivalent to	MRJ410A
Compliant with standard(s)	CE markingTUV RheinlandcULusULKCEN61800-5-2EN61800-5-1EN61800-3EN ISO 13849-1 PLe Cat3EN62061SILCL3IEC61508-5-2EN50581UL508CCSAKCEAC
Benefits	high-speed serial communication
Recommended accessoriescompatible with servo motors	HG-KR053 (0.9A)HG-KR13 (0.8A)HG-MR053 (1A)HG-MR13 (0.9A)
