Bộ điều khiển Servo Mitsubishi MR-J4-40A 0.4kW 220V

Mã sản phẩm: 08557252

Liên hệ

SKU: MR-J4-40A
Thương hiệu: Mitsubishi
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT

Danh mục: Servo

Liên hệ báo giá

Mô tả sản phẩm

Primary brand	Mitsubishi Electric
Main function	AC servo drive
Product series / family name	MELSERVO J4 series
Sub-range name	MR-J4 series
Functions	AC motion servo drive / amplifiersine wave PWM control/current control method2-channel analog monitorSafe torque off (STO)fully closed loop controlload-side encoder interfacespeed control modetorque control modeadvanced vibration suppression control IIadaptive filter IIrobust filterauto tuningone-touch tuningtough drive functiondrive recorder functionmachine diagnosis functionpower monitoring Functionsuper trace controllost motion compensation
Design	built-in dynamic brakebuilt-in regenerative resistor2-wire type communication methodnatural cooling
Supply voltage (AC)	200Vac-240Vac (200V class; 220Vac / 230Vac)
Type of network	Single-phase input (2P) or 3-phase input (3P)
Rated current	2.8A
Rated active power (kW)	400W / 0.4kW
Protection functions	overcurrent shut-offregenerative overvoltage shut-offoverload shut-off (electronic thermal)servo motor overheat protectionencoder fault protectionregenerative fault protectionundervoltage protectioninstantaneous power failure protectionoverspeed protectionexcessive error protectionmagnetic pole detection protectionlinear servo control fault protection
Communication protocol	RS-422RS-485
Net Height (mm)	168 mm
Net Width (mm)	40 mm
Net Depth (mm)	170 mm
Digital inputs	1 x digital input (24Vdc; sink/source) (EM2)1 x digital input (24Vdc; sink/source) (LSP)1 x digital input (24Vdc; sink/source) (LSN)1 x digital input (24Vdc; sink/source) (SON)1 x digital input (24Vdc; sink/source) (RES)1 x digital input (24Vdc; sink/source) (PC / ST1 / RS2)1 x digital input (24Vdc; sink/source) (TL / ST2 / RS1)1 x digital input (24Vdc; sink/source) (SP1)1 x digital input (24Vdc; sink/source) (SP2)
Digital outputs	1 x digital output (rly. contact type) (ALM)1 x digital output (rly. contact type) (ZSP)1 x digital output (rly. contact type) (TLC / VLC)1 x digital output (rly. contact type) (INP / SA)1 x digital output (rly. contact type) (RD)
Analog inputs	1 x analog input (0-10Vdc) (TLA / TC)1 x analog input (-10…+10Vdc) (VC / VLA)
Analog outputs	1 x analog output (-10…+10Vdc) (MO1)1 x analog output (-10…+10Vdc) (MO2)
Degree of protection	IP20
Dimensions	H168mm x W40mm x D170mm
Ambient air temperature for operation	0…+55 °C
Ambient air temperature for storage	-20°C…+65 °C
Current consumption	2.6A input
Power consumption(drive auxiliary power consumption)	30 W
Order code / Manufacturer SKU	MR-J4-40A
Manufacturer product status	Commercialized
Equivalent to	MRJ440A
Compliant with standard(s)	CE markingTUV RheinlandcULusULKCEN61800-5-2EN61800-5-1EN61800-3EN ISO 13849-1 PLe Cat3EN62061SILCL3IEC61508-5-2EN50581UL508CCSAKCEAC
Benefits	high-speed serial communication
Recommended accessoriescompatible with servo motors	HG-KR43 (2.6A)HG-MR43 (2.6A)LM-H3P2A-07P-BSS0 (1.8A)LM-H3P3A-12P-CSS0 (1.7A)LM-K2P1A-01M-2SS1 (2.3A)LM-U2PAD-10M-0SS0 (1.9A)LM-U2PAF-15M-0SS0 (2.7A)TM-RG2M004E30 (1.3A)TM-RU2M004E30 (1.3A)TM-RG2M009G30 (2.2A)TM-RU2M009G30 (2.2A)TM-RFM004C20 (2.2A)
